Specification
DOWNLOAD SPECS| Inside Diameter, End 2 | 0.54 inch / 13.59 mm |
| Largest Outside Diameter | 13.83 inch / 351.33 mm |
| Outside Diameter, End 2 | 13.83 inch / 351.33 mm |
| Rated Flow | 24.21 CU. m/m |
| Overall Length | 16.06 inch / 407.90 mm |
| Full Life Efficiency | 99.9 |
| Height | 16.05 inch / 407.67 mm |
| Inside Diameter, End 1 | 9.48 inch / 240.74 mm |
| Largest End Inside Diameter | 9.48 in / 240.74 mm |
| Inside Diameter | 9.48 inch / 240.70 mm |
| Media Type | Cellulose |
| Applicable Region | North America, Europe, South East Asia |
Product Comments
Same as AF1871M w/o gasket. For Magnum Version use AF361M 250806 Bolt Seal Included
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 1 | |||
| 12V-71 Series | 1 | ||
| 16V-71N | 1 | ||
| 16V-71N | 1 | ||
| 8V-71N FRONT ENGINE | 1 | ||
| 12V-71 Series | 1 | ||
| 16V-71N | 1 | ||
| 12V71 | 1 | ||
| 12V-71 Series | 1 | ||
| 16V-71N | 1 | ||
| 12V-71T FRONT ENGINE | 1 | ||
| 1 | |||
| 1 | |||
| 12V-71N FRONT ENGINE | 1 | ||
| 12V-71 Series | 1 | ||
| 1 | |||
| 1 | |||
| 16V-71N | 1 | ||
| DETROIT DIESEL | 1 | ||
| 12V-71 Series | 1 | ||
| 12V-71 Series | 1 | ||
| 16V-71N | 1 | ||
| 12V-71 Series | 1 | ||
| 16V-71N | 1 | ||
| 12V71 | 1 | ||
| 12V71 | 1 | ||
| C8TFL | 1 | ||
| 8V-92 Series | 1 | ||
| 12V71 | 1 | ||
| 12V71 | 1 | ||
| 12V71 | 1 | ||
| 12V71 | 1 | ||
| 12V71 | 1 | ||
| 12V71 | 1 | ||
| 12V71 | 1 |
