Specification
DOWNLOAD SPECS| Overall Length | 10.34 inch / 262.60 mm |
| Largest Outside Diameter | 19.25 inch / 488.95 mm |
| Height | 10.34 inch / 262.70 mm |
| Efficiency Test Std | ISO 5011 |
| Full Life Efficiency | 99.95 |
| Outside Diameter, End 2 | 19.35 inch / 491.50 mm |
| Inside Diameter | 12.89 inch / 327.40 mm |
| Inside Diameter, End 1 | 12.93 inch / 328.50 mm |
| Rated Flow | 38.00 CU. m/m |
| Media Type | Cellulose |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific |
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| C18 | 2011 | 1 | |
| 2008 | 1 | ||
| 3516B | 1 | ||
| 3512B | 1 | ||
| 3516 | 1 | ||
| 66Z1 | 1 | ||
| 3508B | 2 | ||
| 65Z1 | 1 | ||
| 70Z1 | 1 | ||
| 1 | |||
| 3306T | 2019 | 1 | |
| 3306T | 2018 | 1 | |
| 3306T | 2017 | 1 | |
| 3306T | 2016 | 1 | |
| 3306T | 2015 | 1 | |
| 3306T | 2014 | 1 | |
| 3306T | 2013 | 1 | |
| 2012 | 1 | ||
| 3306T | 2012 | 1 | |
| C18 | 2012 | 1 | |
| 2012 | 1 | ||
| 2012 | 1 | ||
| G3508 | 2011 | 1 | |
| 3412 | 2011 | 1 | |
| G3512 | 2011 | 1 | |
| SCT673 | 2011 | 1 | |
| 3508C | 2011 | 1 | |
| G3508TA | 2008 | 1 | |
| G3508 | 1 | ||
| 3516 | 1 | ||
| 50Y1-UP | 1 | ||
| 3512 | 1 | ||
| 3306 | 1 | ||
| 66Z1-UP | 1 | ||
| 3612 | 1 | ||
| 3508 | 2 | ||
| 68Z1-UP | 1 | ||
| G3516TA | 2 | ||
| G3512TA | 2 | ||
| G3516 | 1 | ||
| 3306 | 1 | ||
| G3524 | 1 | ||
| 3512C | 2 | ||
| G3412C | 1 | ||
| G3512 | 1 | ||
| G3412 | 1 | ||
| G3508TA | 1 | ||
| C6.6 | 1 | ||
| 97Y1-UP | 1 | ||
| 2516 | 1 | ||
| 69Z1-UP | 1 | ||
| G3516B | 1 |
