Specification
DOWNLOAD SPECS| Inside Diameter, End 2 | 7.73 inch / 196.29 mm |
| Inside Diameter, End 1 | 0.66 inch / 16.89 mm |
| Fin Diameter | 15.80 inch / 401.32 mm |
| Rated Flow | 465.00 CFM |
| Media Type | Cellulose |
| Largest End Inside Diameter | 7.69 in / 195.33 mm |
| Inside Diameter | 7.69 inch / 195.30 mm |
| Height | 10.50 inch / 266.62 mm |
| Outside Diameter, End 2 | 12.08 inch / 306.88 mm |
| Efficiency Test Std | ISO 5011 |
| Full Life Efficiency | 99.9 |
| Length | 10.00 in / 254.00 mm |
| Largest Outside Diameter | 12.00 inch / 304.80 mm |
| Overall Length | 10.00 inch / 254.00 mm |
| Applicable Region | North America, China, Europe, South America, South East Asia, South Pacific |
Product Comments
For Magnum Version, use AF478KM.
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 3406E | 1994 | 1 | |
| Series 60 | 1988 | 1 | |
| 3406 | 1985 | 1 | |
| 3406 | 1 |
