Specification
DOWNLOAD SPECS| Media Type | StrataPore |
| Largest OD | 4.26 inch / 108.20 mm |
| Gasket Inside Diameter | 2.46 inch / 62.59 mm |
| Seam OD | 4.26 in / 108.20 mm |
| EFFICIENCY, TWA BY SAE J 1985 | 98.7% |
| Length / Overall Height | 10.44 inch / 265.15 mm |
| Thread Size | 13/16-12 UNS-2B |
| Length | 10.44 inch / 265.15 mm |
| Gasket OD | 2.82 inch / 71.63 mm |
| Standpipe | NO |
| MICRON RATING BY SAE J 1985 | 50.00 micron |
| Applicable Region | North America, South Pacific, Mexico and Central America |
Product Comments
Cummins ISX engines
