Specification
DOWNLOAD SPECS| Gasket OD | 2.83 inch / 71.98 mm |
| Largest OD | 3.68 inch / 93.53 mm |
| Efficiency Test Std | SAE J905 |
| Primary Particle Efficiency | 6.50 micron (c) @ 98.7% |
| Gasket Inside Diameter | 2.46 inch / 62.53 mm |
| Length | 6.92 inch / 175.76 mm |
| Thread Size | M20X1.5-6H |
| Hydrostatic Burst Minimum | 203.00 psi / 1400.00 kPa |
| Rated Flow | 1.66 gpm / 6.30 L/min |
| Media Type | Cellulose |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific, Mexico and Central America, APAC |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 6CTAA8.3-CE | 1 | ||
| SAA6D107E-1 | 2011 | 1 | |
| SAA4D107E-1 | 2010 | 1 | |
| KOMATSU | 2008 | 1 | |
| KOMATSU | 2008 | 1 | |
| SAA6D107E-1 | 1 | ||
| SAA6D107E-1 | 1 | ||
| 1 | |||
| 1 | |||
| SAA4D107E-1 | 1 | ||
| SAA6D107E-1 | 1 | ||
| QSC8.3-C250 | 2007 | 1 | |
| QSB4.5 | 2007 | 1 | |
| QSC8.3-C250 | 2007 | 1 | |
| QSB4.5 | 2007 | 1 | |
| SA6D108-1 | 2020 | 1 | |
| SAA6D102E | 2020 | 1 | |
| SAAD107E-1 | 2013 | 1 | |
| SAAD107E-1 | 2012 | 1 | |
| SAA4D107E-1 | 2012 | 1 | |
| QSB4.5 | 2011 | 1 | |
| SAAD107E-1 | 2011 | 1 | |
| QSB4.5 | 2011 | 1 | |
| SAAD107E-1 | 2010 | 1 | |
| SAA4D107E-1 | 2010 | 1 | |
| SAAD107E-1 | 2009 | 1 | |
| QSB4.5 | 2008 | 1 | |
| QSB4.5 | 2008 | 1 | |
| QSB4.5 | 2008 | 1 | |
| QSB4.5 | 2008 | 1 | |
| QSB4.5 | 2008 | 1 | |
| QSB4.5 | 2008 | 1 | |
| SAA6D107E-1 | 2008 | 1 | |
| SAAD107E-1 | 2008 | 1 | |
| SAA6 D 107 E | 2008 | 1 | |
| QSB4.5 | 2007 | 1 | |
| QSB4.5 | 2007 | 1 | |
| QSB4.5 | 2007 | 1 | |
| QSB4.5 | 2007 | 1 | |
| QSB 6.7 | 2007 | 1 | |
| QSB4.5 | 2007 | 1 | |
| QSB4.5 | 1 | ||
| QSB4.5 | 1 | ||
| QSB4.5 | 1 | ||
| QSB4.5 | 1 |
