Specification
DOWNLOAD SPECS| Gasket OD | 2.81 inch / 71.44 mm |
| Largest OD | 4.26 inch / 108.20 mm |
| Standpipe | No |
| Gasket Inside Diameter | 2.50 inch / 63.50 mm |
| Rated Flow | 2.64 gpm / 10.00 L/min |
| Length | 8.76 inch / 222.50 mm |
| Efficiency Test Std | ISO 19438 |
| Thread Size | 1-14 UN 2B |
| Primary Particle Efficiency | 5.80 micron (c) @ 95% |
| Applicable Region | North America |
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| C15 | 2010 | 1 | |
| C15 | 2010 | 1 | |
| C15 | 2009 | 1 | |
| C15 | 2009 | 1 | |
| C11 | 2008 | 1 | |
| C12 | 2008 | 1 | |
| C10 | 2008 | 1 | |
| C15 | 2008 | 1 | |
| 3406 | 2008 | 1 | |
| C10 | 2018 | 1 | |
| C12 | 2018 | 1 | |
| C11 | 2018 | 1 | |
| C11 | 2017 | 1 | |
| C10 | 2017 | 1 | |
| C12 | 2017 | 1 | |
| 3406 | 2017 | 1 | |
| 3406 | 2016 | 1 | |
| C12 | 2016 | 1 | |
| C11 | 2016 | 1 | |
| C10 | 2016 | 1 | |
| 3406 | 2015 | 1 | |
| C12 | 2015 | 1 | |
| C11 | 2015 | 1 | |
| C10 | 2015 | 1 | |
| C11 | 2014 | 1 | |
| C12 | 2014 | 1 | |
| 3406 | 2014 | 1 | |
| C10 | 2014 | 1 | |
| C12 | 2013 | 1 | |
| C11 | 2013 | 1 | |
| 3406 | 2013 | 1 | |
| C10 | 2013 | 1 | |
| 3406 | 2012 | 1 | |
| C12 | 2012 | 1 | |
| C11 | 2012 | 1 | |
| C10 | 2012 | 1 | |
| C12 | 2011 | 1 | |
| C11 | 2011 | 1 | |
| 3406 | 2011 | 1 | |
| C10 | 2011 | 1 | |
| C12 | 2010 | 1 | |
| C11 | 2010 | 1 | |
| C10 | 2010 | 1 | |
| 3406 | 2010 | 1 | |
| 3406 | 2009 | 1 | |
| C11 | 2009 | 1 | |
| C12 | 2009 | 1 | |
| C10 | 2009 | 1 |
