Specification
DOWNLOAD SPECS| Thread Size | 1.00 1/4-12 UNS-2B |
| Length | 11.93 inch / 303.02 mm |
| EMULSIFIED WATER SEPARATION | 95% |
| Gasket Inside Diameter | 3.86 inch / 98.17 mm |
| Test Specification | SAE J905 |
| Rated Flow | 2.99 gpm / 11.33 L/min |
| Largest OD | 4.74 inch / 120.27 mm |
| Standpipe | YES |
| Gasket OD | 4.38 inch / 111.38 mm |
| Hydrostatic Burst Minimum | 145.00 psi / 999.98 kPa |
| Primary Particle Efficiency | 10.10 micron (c) @ 98.7% |
| Applicable Region | North America, China, Europe, South America, South East Asia, South Pacific, Mexico and Central America, APAC |
Product Comments
For Marine engines K35 and K50; same as FS1006 except with metal drain valve.
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| N14-M | 1 | ||
| KT19-M | 1 | ||
| KTA19-M | 1 | ||
| QSK60-M | 1 | ||
| KTA19-M3 | 1 | ||
| KTA19-M4 | 1 | ||
| QSM11-M | 1 | ||
| KT-19 | 2009 | 1 | |
| KT-19 | 2008 | 1 |
