Specification
DOWNLOAD SPECS| Media Type | StrataPore |
| Length | 6.47 in / 164.29 mm |
| End 2 OD | 4.62 inch / 117.35 mm |
| EMULSIFIED WATER SEPARATION | 95% |
| MICRON RATING BY SAE J 1985 | 10.00 micron |
| Element Collapse/Burst, Min | 827.00 kPa |
| Largest End ID | 0.65 in / 16.51 mm |
| Largest OD | 4.62 inch / 117.35 mm |
| End 1 ID | 0.65 inch / 16.51 mm |
| EFFICIENCY, TWA BY SAE J 1985 | 98.7% |
| FREE WATER SEPARATION | 95% |
| Rated Flow | 8.83 cu. m/m |
| Primary Particle Efficiency | 98.7% |
| Length / Overall Height | 6.47 inch / 164.29 mm |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific, Mexico and Central America |
Product Comments
Maximum Engine Protection
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| ISX15 | 2017 | 1 | |
| ISX15 | 2016 | 1 | |
| ISX15 | 2015 | 1 | |
| ISX15 | 2014 | 1 | |
| ISX15 | 2013 | 1 | |
| ISX15 | 2013 | 1 | |
| ISX15 | 2007 | 1 | |
| ISX15 | 2004 | 1 | |
| ISX | 1 | ||
| ISM11 | 1 |
