Specification
DOWNLOAD SPECS| Thread Size | 13/16-18 UNS-2B |
| Largest Outside Diameter | 3.68 inch / 93.52 mm |
| Gasket Outside Diameter | 2.83 inch / 71.98 mm |
| Emulsified Water Separation | 95% |
| Capacity Test Specification | SAE J905 |
| Rated Flow | 1.00 gpm / 3.78 L/min |
| Height | 6.97 inch / 177.04 mm |
| Gasket Inside Diameter | 2.46 inch / 62.53 mm |
| Standpipe | NO |
| Hydrostatic Burst Minimum | 299.93 psi / 2068.50 kPa |
| Primary Particle Efficiency | 10.10 micron (c) @ 98.7% |
| Applicable Region | North America, Europe, South America, South East Asia, Mexico and Central America |
Product Comments
Stratapore Media
