Specification
DOWNLOAD SPECS| Media Type | Stratapore |
| Gasket Inside Diameter | 2.46 inch / 62.50 mm |
| Hydrostatic Burst Minimum | 284.20 psi / 1960.00 kPa |
| Thread Size | 13/16-18 UNF 2B |
| Rated Flow | 1.00 gpm / 3.80 L/min |
| Largest OD | 3.69 inch / 93.60 mm |
| Gasket OD | 2.83 inch / 72.00 mm |
| Test Specification | SAE J905 |
| Primary Particle Efficiency | 5.00 micron @ 95% |
| Applicable Region | North America, China, Europe, South America, South East Asia, South Pacific |
Product Comments
The drain valve and the pipe from the previous filter need to be reused. Please refer to the FS19652V for the filter with drain valve and pipe.
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| S3.8-G7 | 1 | ||
| 1 | |||
| S3.8G4 | 1 | ||
| S3.8-G7 | 1 | ||
| 497 BSIII | 1 |
