Specification
DOWNLOAD SPECS| Thread Size | M16 X 1.5-6H INT |
| Length | 6.25 inch / 158.75 mm |
| Gasket OD | 2.76 inch / 70.00 mm |
| EMULSIFIED WATER SEPARATION | 95% |
| Test Specification | ISO TR13353 |
| Rated Flow | 0.44 gpm / 1.67 L/min |
| Largest OD | 3.03 inch / 77.00 mm |
| Gasket Inside Diameter | 2.45 inch / 62.30 mm |
| Standpipe | NO |
| Hydrostatic Burst Minimum | 217.50 psi / 1500.00 kPa |
| Primary Particle Efficiency | 6.50 micron (c) @ 98.7% |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific, Mexico and Central America |
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 2008 | 1 | ||
| 2008 | 1 | ||
| 2008 | 1 | ||
| 2008 | 1 | ||
| 2008 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2002 | 1 | ||
| 1 | |||
| 1 | |||
| 8045.25 | 1 | ||
| 8045.05 | 1 | ||
| 1 | |||
| 1 | |||
| 8045.25 | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| 8045.06 | 1 | ||
| 1 | |||
| 8045.05 | 1 | ||
| 1 | |||
| 8045.06 | 1 | ||
| 1 | |||
| 2012 | 1 | ||
| 2012 | 1 | ||
| 2009 | 1 | ||
| IVECO | 2008 | 1 | |
| 2008 | 1 | ||
| 2008 | 1 | ||
| IVECO | 2008 | 1 | |
| IVECO | 2008 | 1 | |
| 2008 | 1 | ||
| IVECO | 2008 | 1 | |
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| 2007 | 1 | ||
| NEW HOLLAND | 2005 | 1 | |
| NEW HOLLAND | 2005 | 1 | |
| NEW HOLLAND | 2005 | 1 | |
| NEW HOLLAND | 2005 | 1 | |
| NEW HOLLAND | 2004 | 1 | |
| NEW HOLLAND | 2004 | 1 | |
| NEW HOLLAND | 2004 | 1 | |
| NEW HOLLAND | 2004 | 1 | |
| NEW HOLLAND | 2003 | 1 | |
| NEW HOLLAND | 2003 | 1 | |
| NEW HOLLAND | 2003 | 1 | |
| 6.7L | 2002 | 1 | |
| IVECO | 2002 | 1 | |
| 2002 | 1 | ||
| 6T-590 | 1 | ||
| 1 | |||
| 445T/M2 | 1 | ||
| 1 | |||
| 445T/M2 | 1 | ||
| 445T/M2 | 1 |
