Specification
DOWNLOAD SPECS| Largest OD | 5.10 inch / 129.54 mm |
| Gasket OD | 4.13 inch / 105.00 mm |
| Thread Size | 1.25-12 UNF 2B |
| Gasket Inside Diameter | 3.59 inch / 91.20 mm |
| Length | 13.34 inch / 338.83 mm |
| Primary Particle Efficiency | 10.00 micron (c) @ 95% |
| Media Type | StrataPore |
| Rated Flow | 1.8 |
| Applicable Region | North America, China, Europe, South America, South East Asia, South Pacific, Mexico and Central America |
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| SAA6D140E-5 | 2011 | 1 | |
| SAA6D125E-5 | 2011 | 1 | |
| SAA6D170E-5A | 2009 | 2 | |
| SAA6D125E-5 | 2008 | 1 | |
| 2008 | 1 | ||
| SAA6D140E-3 | 2008 | 1 | |
| SAA6D125E-5 | 2008 | 1 | |
| 2008 | 1 | ||
| 2008 | 1 | ||
| SAA6D140E-5 | 2007 | 2 | |
| SAA6D140E-5 | 2007 | 2 | |
| SAA6D140E-5 | 2007 | 2 | |
| SAA6D140E-5 | 2007 | 2 | |
| SAA12V140E-3 | 2007 | 1 | |
| SAA6D140E-5 | 2007 | 2 | |
| SAA6D140E-5 | 2007 | 2 | |
| SAA6D140E-5 | 2007 | 2 | |
| SAA6D140E-5 | 2007 | 2 | |
| SAA12V140E-3 | 2007 | 2 | |
| SAA6D140E-5 | 2006 | 1 | |
| SAA6D140E-5 | 2006 | 1 | |
| SAA6D140E | 2006 | 1 | |
| SAA6D140E-5 | 2006 | 1 | |
| SAA6D125E-5 | 2006 | 1 | |
| SAA6D140E-5 | 2006 | 1 | |
| SAA6D125E-5 | 2006 | 1 | |
| SAA6D140E | 2006 | 1 | |
| 2006 | 1 | ||
| 2006 | 1 | ||
| 2006 | 1 | ||
| SAA6D170E-5 | 2005 | 1 | |
| KOMATSU | 2005 | 1 | |
| SAA6D125-3 | 2004 | 1 | |
| SAA6D125-3 | 2004 | 1 | |
| SA6D140E-3 | 2004 | 1 | |
| SA6D140E-3 | 2004 | 1 | |
| SAA6D125-3 | 2004 | 1 | |
| 2004 | 1 | ||
| 1 | |||
| SDA6D140E | 1 | ||
| 1 | |||
| 2 | |||
| SAA6D125E-5 | 1 | ||
| SA6D125E-3 | 1 | ||
| SAA6D140E-5 | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| 1 | |||
| SAA6D140E-5AG | 1 | ||
| SDA6D140E | 1 | ||
| SA6D125E-3 | 1 | ||
| SAA6D125E-5F | 1 | ||
| SAA6D140E-5 | 2 | ||
| 1 | |||
| SAAD140E | 1 | ||
| SAA6D125E-5 | 1 | ||
| 1 | |||
| SAA6D140E-5 | 2 | ||
| 1 | |||
| SAA6D140E-5 | 1 | ||
| 1 | |||
| SAA6D125E-5 | 1 | ||
| 1 | |||
| SAA12V140E-3 | 2 | ||
| 1 | |||
| SAA12V140E-3 | 1 | ||
| SAA6D125E-5F | 1 | ||
| SAA12V140E | 2 | ||
| SAA6D170E-5 | 2 | ||
| 1 | |||
| SAA6D125E-5 | 1 | ||
| SAA6D125E-5 | 1 | ||
| SAA6D125E-3K | 1 | ||
| 1 | |||
| SAA6D140E-5 | 2 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| SAA6D140E-5 | 1 | ||
| 1 | |||
| SAA6D140E-5 | 2 | ||
| 1 | |||
| SAA6D140E-5 | 1 | ||
| SAA6D140E-5 | 2 | ||
| 1 | |||
| SAA6D125E-5 | 1 | ||
| SAA6D125E-5 | 1 | ||
| SAA12V140 | 2 | ||
| SAA6D170E-5 | 2 | ||
| SAA6D102E | 1 | ||
| 1 | |||
| SAA6D102E | 1 | ||
| 1 | |||
| SAA6D125E-5F | 1 | ||
| 1 | |||
| SAA6D125E-5 | 1 | ||
| 1 | |||
| SAA6D140E-5 | 1 | ||
| 1 | |||
| SAA12V140 | 2 | ||
| 1 | |||
| SAA6D125E-5F | 1 | ||
| 1 | |||
| 1 | |||
| SAA6D125E-5F | 1 | ||
| SAA6D140E-5 | 1 | ||
| SAA6D125E | 1 | ||
| SAA6D140E-5 | 2 | ||
| SAA6D125E-5 | 1 | ||
| 1 | |||
| 1 | |||
| SAA6D170E-5 | 2 | ||
| SAA12V140E-3 | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| SAA6D140E | 1 | ||
| SAA6D140E-5 | 2 | ||
| SAA6D125E-5 | 1 | ||
| SAA6D125E-5 | 1 | ||
| 1 | |||
| SAA6D125E-5 | 1 | ||
| 1 | |||
| SAA6D170E-5 | 1 | ||
| 1 | |||
| SAA6D125E-3K | 1 | ||
| 1 | |||
| SAA6D170E-5 | 2 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| 1 | |||
| 1 | |||
| SAA12V140E-3 | 2 | ||
| 1 |
