Specification
DOWNLOAD SPECS| Length | 11.61 inch / 294.89 mm |
| Gasket OD | 3.18 inch / 80.77 mm |
| Test Specification | SAE J905 |
| Thread Size | 1-14 UNF 2B |
| Largest OD | 4.59 inch / 116.59 mm |
| Gasket Inside Diameter | 2.77 inch / 70.46 mm |
| Rated Flow | 2.00 gpm / 7.57 lpm |
| Primary Particle Efficiency | 10.10 micron (c) @ 95% |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific |
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 6090HTJ31 | 2019 | 1 | |
| 6081HF070 (POWERTECH 8.1L) | 1 | ||
| 6081AFM01 (POWERTECH 8.1L) | 1 | ||
| 4R1003 | 2018 | 1 | |
| 4R1000 | 2018 | 1 | |
| 4R1000 | 2017 | 1 | |
| C9 | 2017 | 1 | |
| C4.4 | 2017 | 1 | |
| 4R1002 | 2016 | 1 | |
| OM 471 LA | 2014 | 1 | |
| C11 | 2013 | 1 | |
| TCD2012 L04 | 2013 | 1 | |
| C9 | 2012 | 1 | |
| C7 | 2012 | 1 | |
| C13 | 2012 | 1 | |
| C13 | 2012 | 1 | |
| C9 | 2011 | 1 | |
| MX-13 | 2010 | 1 | |
| MX-13 | 2010 | 1 | |
| PR265 EURO5/EEV | 2010 | 1 | |
| 4JG1 | 2009 | 1 | |
| C6.6 | 2009 | 1 | |
| C6.6 | 2008 | 1 | |
| C7 | 2008 | 1 | |
| C11 | 1 | ||
| TCD2012 L04 | 1 |
