Specification
DOWNLOAD SPECS| Height | 12.01 inch / 305.00 mm |
| Gasket Outside Diameter | 4.31 inch / 109.50 mm |
| Media Type | Cellulose |
| Hydrostatic Burst Minimum | 301.60 psi / 2080.00 kPa |
| Primary Particle Efficiency | 10.00 micron @ 98.7% |
| Rated Flow | 1.32 gpm / 5.00 L/min |
| Largest Outside Diameter | 5.35 inch / 136.00 mm |
| Emulsified Water Separation | 95% / 95 |
| Gasket Inside Diameter | 3.84 inch / 97.50 mm |
| Capacity Test Specification | SAE J905 |
| Thread Size | 1.25-12 UNF 2B |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 2011 | 1 | ||
| 2011 | 1 | ||
| C32TA ACERT | 2021 | 1 | |
| C11-370 | 2019 | 1 | |
| C11-370 | 2018 | 1 | |
| 3516BTA | 2018 | 1 | |
| C11-370 | 2017 | 1 | |
| 3516BTA | 2017 | 1 | |
| 3516BTA | 2016 | 1 | |
| C11-370 | 2016 | 1 | |
| C18 | 2015 | 1 | |
| C11-370 | 2015 | 1 | |
| 3516BTA | 2015 | 1 | |
| C175 | 2014 | 1 | |
| 3516BTA | 2014 | 1 | |
| C175-20 | 2014 | 1 | |
| C11-370 | 2014 | 1 | |
| C175-16 | 2013 | 1 | |
| C175 | 2013 | 1 | |
| C175-16 | 2013 | 1 | |
| 3516BTA | 2013 | 1 | |
| C11-370 | 2013 | 1 | |
| 2012 | 1 | ||
| C11-370 | 2012 | 1 | |
| C15 | 2012 | 1 | |
| 2012 | 1 | ||
| 2011 | 1 | ||
| 2011 | 1 | ||
| 2011 | 1 | ||
| 1 | |||
| C175 | 1 |
