Specification
DOWNLOAD SPECS| Largest OD | 4.35 inch / 110.49 mm |
| Standpipe | NO |
| Gasket Inside Diameter | 4.73 in / 120.14 mm |
| EMULSIFIED WATER SEPARATION | 60% |
| Test Specification | SAE J905 |
| Length | 9.60 inch / 243.84 mm |
| Media Type | Cellulose |
| Largest End ID | 0.83 inch / 21.01 mm |
| Primary Particle Efficiency | 45.00 micron (c) @ 99.5% |
| Rated Flow | 3.00 gpm / 11.35 L/min |
| Applicable Region | North America, China, Europe, South America, South East Asia, South Pacific, Mexico and Central America, APAC |
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| MBE4000 | 2010 | 1 | |
| Series 60 | 2010 | 1 | |
| C15 | 2010 | 1 | |
| Series 60 | 2010 | 1 | |
| Series 60 | 2010 | 1 | |
| C15 | 2010 | 1 | |
| MBE4000 | 2010 | 1 | |
| C15 | 2010 | 1 | |
| Series 60 | 2009 | 1 | |
| MBE4000 | 2009 | 1 | |
| MBE4000 | 2009 | 1 | |
| Series 60 | 2009 | 1 | |
| C15 | 2009 | 1 | |
| C15 | 2009 | 1 | |
| C15 | 2009 | 1 | |
| Series 60 | 2009 | 1 | |
| N14 | 2008 | 1 | |
| MBE4000 | 2008 | 1 | |
| C15 | 2008 | 1 | |
| Series 60 | 2008 | 1 | |
| N14 | 2008 | 1 | |
| N14 | 2008 | 1 | |
| C15 | 2008 | 1 | |
| C15 | 2008 | 1 | |
| Series 60 | 2008 | 1 | |
| Series 60 | 2008 | 1 | |
| Series 60 | 2007 | 1 | |
| Series 60 | 2007 | 1 | |
| Series 60 | 2007 | 1 | |
| C15 | 2006 | 1 | |
| Series 60 | 2005 | 1 | |
| Series 60 | 2005 | 1 | |
| Series 60 | 2005 | 1 | |
| ISM11 | 2002 | 1 | |
| ISX15 | 2001 | 1 | |
| M11 | 2000 | 1 | |
| M11 | 1999 | 1 | |
| M11 | 1997 | 1 | |
| M11 | 1996 | 1 | |
| M11 | 1995 | 1 | |
| L10 | 1989 | 1 | |
| L10 | 1 | ||
| 3176 | 1 | ||
| 3406 | 1 | ||
| NTC | 1 | ||
| C12 | 1 | ||
| 3406E | 1 | ||
| C10 | 1 | ||
| ISM11 | 1 | ||
| MP8 | 2017 | 1 | |
| MP7 | 2017 | 1 | |
| MP8 | 2017 | 1 | |
| MP7 | 2017 | 1 | |
| MP8 | 2016 | 1 | |
| MP8 | 2016 | 1 | |
| MP7 | 2016 | 1 | |
| MP7 | 2016 | 1 | |
| MP7 | 2015 | 1 | |
| MP8 | 2015 | 1 | |
| MP8 | 2015 | 1 | |
| MP7 | 2015 | 1 | |
| MP7 | 2014 | 1 | |
| MP8 | 2014 | 1 | |
| MP7 | 2014 | 1 | |
| MP8 | 2014 | 1 | |
| MP8 | 2013 | 1 | |
| MP8 | 2013 | 1 | |
| MP7 | 2013 | 1 | |
| MP7 | 2013 | 1 | |
| MP8 | 2012 | 1 | |
| MP7 | 2012 | 1 | |
| MP7 | 2012 | 1 | |
| MP8 | 2012 | 1 | |
| MP8 | 2011 | 1 | |
| MP8 | 2011 | 1 | |
| MP7 | 2011 | 1 | |
| MP7 | 2011 | 1 | |
| MP7 | 2010 | 1 | |
| MP8 | 2010 | 1 | |
| MP7 | 2010 | 1 | |
| MP8 | 2010 | 1 | |
| MP8 | 2009 | 1 | |
| MP7 | 2009 | 1 | |
| MP8 | 2009 | 1 | |
| MP7 | 2009 | 1 | |
| MP8 | 2008 | 1 | |
| MP7 | 2008 | 1 | |
| MP7 | 2008 | 1 | |
| MP8 | 2008 | 1 | |
| SPS343 | 2011 | 2 | |
| SPT343 | 2011 | 2 | |
| 2008 | 2 | ||
| 2008 | 2 | ||
| 2008 | 2 | ||
| CAT | 2008 | 2 | |
| OM501LA | 1 | ||
| 3TNV84T | 1 | ||
| OM501LA | 1 | ||
| DT466E | 1 | ||
| 1106D-E70TAG4 | 2018 | 1 | |
| 1106D-E70TAG2 | 2016 | 1 | |
| KTA50 | 2016 | 1 | |
| 3516C | 2015 | 1 | |
| 3516CTA | 2013 | 1 | |
| QSX15 | 2012 | 1 | |
| KTA50 | 2012 | 1 | |
| QSK23-G3 | 2011 | 1 | |
| SPF343 | 2011 | 2 | |
| SPF343C | 2011 | 2 | |
| 3616 | 2011 | 2 | |
| 3512BTA | 2010 | 1 | |
| 3512BTA | 2009 | 1 | |
| QSM 11 TIER 3 | 2008 | 1 | |
| MBE4000 | 2008 | 1 | |
| QSK23-G3 | 2008 | 1 | |
| TCD2016V16G2 | 2008 | 1 | |
| QSM 11 TIER 3 | 2008 | 1 | |
| QSM 11 TIER 3 | 2008 | 1 | |
| QSM 11 TIER 3 | 2008 | 1 | |
| QSX 15 TIER 3 | 2008 | 1 | |
| QSX 15 TIER 3 | 2008 | 1 | |
| QSX 15 TIER 3 | 2008 | 1 | |
| 3512BTA | 2008 | 1 | |
| G3508TA | 2008 | 1 | |
| OM501LA | 2001 | 1 | |
| OM501LA | 2001 | 1 | |
| G3516TA | 1 | ||
| S6R-Y1TAA1 | 1 | ||
| S12A2-YTAA1 | 4 | ||
| 6CT8.3 | 1 | ||
| 6CT8.3 | 1 | ||
| S12A2-YTAA1 | 4 | ||
| 6CT8.3 | 1 | ||
| 6CT8.3 | 1 | ||
| 2 | |||
| QSM11 | 1 | ||
| S12A-Y1T | 1 | ||
| QSM11 | 1 | ||
| 3512C | 2 | ||
| 2 | |||
| S12A-Y1T | 1 |
