Specification
DOWNLOAD SPECS| Length | 9.80 inch / 249.00 mm |
| Gasket OD | 3.54 inch / 89.90 mm |
| Media Type | Stratapore |
| Test Specification | SAE J905 |
| Rated Flow | 1.51 gpm / 5.70 L/min |
| Largest OD | 3.68 inch / 93.50 mm |
| EMULSIFIED WATER SEPARATION | 95% / 95 |
| Gasket Inside Diameter | 3.03 inch / 77.00 mm |
| Primary Particle Efficiency | 10.00 micron (c) @ 98.7% |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 7A260 | 2005 | 1 | |
| 7A310 | 2005 | 1 | |
| 7A310 | 2005 | 1 | |
| 7A260 | 2005 | 1 | |
| NGD 370 | 2007 | 1 | |
| ISC8.3 | 2007 | 1 | |
| ISC8.3 | 2007 | 1 | |
| ISC320 | 2006 | 1 | |
| 4.08 TCE | 2005 | 1 | |
| 6.12 TCE | 2005 | 1 | |
| ISC320 | 2005 | 1 | |
| 6.12 TCE | 2005 | 1 | |
| 6.12 TCE | 2005 | 1 | |
| 6.12 TCE | 2004 | 1 | |
| 6.12 TCAE | 2004 | 1 | |
| 4.12 TCAE | 2004 | 1 | |
| 4.12 TCAE | 2004 | 1 | |
| 6.12 TCAE | 2004 | 1 | |
| 6.12 TCE | 2004 | 1 | |
| 4.12 TCE | 2004 | 1 | |
| 4.12 TCAE | 2004 | 1 | |
| 6.12 TCAE | 2004 | 1 | |
| 6.12 TCAE | 2004 | 1 | |
| 4.12 TCE | 2003 | 1 | |
| 4.12 TCE | 2003 | 1 | |
| ISBe | 2003 | 1 | |
| 4.12 TCE | 2003 | 1 | |
| ISBe | 2003 | 1 | |
| 4.12 TCE | 2003 | 1 | |
| NGD 370 | 1 | ||
| NGD 370 | 1 |
