Specification
DOWNLOAD SPECS| Thread Size | M20X1.5-6H |
| Gasket Inside Diameter | 2.26 inch / 57.45 mm |
| Largest OD | 3.34 inch / 84.96 mm |
| Pressure Valve | Yes |
| Primary Particle Efficiency | 24.60 micron (c) @ 100% |
| Gasket OD | 2.52 inch / 64.01 mm |
| Length | 3.52 inch / 89.41 mm |
| Hydrostatic Burst Minimum | 203.00 psi / 1400.00 kPa |
| Rated Flow | 2.51 gpm / 9.50 L/min |
| Applicable Region | North America, China, Europe, South America, South East Asia, South Pacific, Mexico and Central America |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| A2000 | 1 | ||
| 3A1.7 | 1 | ||
| A900 | 1 | ||
| 4AT2.3-G2 | 1 | ||
| A1700 | 1 | ||
| 4AT2.3-G1 | 1 | ||
| A1400 | 1 | ||
| A2300T | 1 | ||
| A2300 | 1 | ||
| 3A1.7-G1 | 1 | ||
| 4AT2.3 | 1 | ||
| 4A2.0 | 1 | ||
| 3A1.4 | 1 | ||
| 3A1.4-G1 | 1 | ||
| 4A2.3-G1 | 1 | ||
| 4A2.0-G1 | 1 | ||
| 4A2.3 | 1 | ||
| A1100N2 | 2017 | 1 | |
| A 2300ESN | 2010 | 1 | |
| A2300T | 2009 | 1 | |
| A2300 | 2008 | 1 | |
| A2300 | 2008 | 1 | |
| A2300 | 2008 | 1 | |
| A2300 | 2008 | 1 | |
| CUMMINS | 2008 | 1 | |
| A2300 | 2008 | 1 | |
| A1400 | 2008 | 1 | |
| A2300 | 2008 | 1 | |
| A2300 | 2008 | 1 | |
| A2300 | 2008 | 1 | |
| A2300 | 2008 | 1 | |
| A2300 | 2008 | 1 | |
| A2300 | 2008 | 1 | |
| A2300 | 2007 | 1 | |
| A1400 | 2007 | 1 | |
| A2300T | 2007 | 1 | |
| A2300 | 2007 | 1 | |
| A2300 | 2007 | 1 | |
| A2300 | 2007 | 1 | |
| A2300 | 2007 | 1 | |
| A2300 | 2007 | 1 | |
| A1700 | 2007 | 1 | |
| A2300T | 2007 | 1 | |
| A2300 | 2007 | 1 | |
| 2006 | 1 | ||
| A2000 | 2004 | 1 | |
| A2000 | 2004 | 1 | |
| A2300 | 2004 | 1 | |
| A2300 | 1 |
