Specification
DOWNLOAD SPECS| Thread Size | M26X1.5-6H |
| Gasket OD | 3.01 inch / 76.40 mm |
| Length | 6.30 inch / 160.00 mm |
| Pressure Valve Opening Pressure | 98.70 kPa |
| Pressure Valve | Yes |
| Media Type | Cellulose |
| Gasket Inside Diameter | 2.73 inch / 69.40 mm |
| Largest OD | 3.28 inch / 83.40 mm |
| Rated Flow | 2.64 gpm / 10.00 L/min |
| Hydrostatic Burst Minimum | 213.30 psi / 1471.00 kPa |
| Primary Particle Efficiency | 38.18 micron (c) @ 98.7% |
| Length / Overall Height | 6.35 inch / 161.30 mm |
| Applicable Region | North America, Europe, South East Asia, South Pacific |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 4JJ1X | 2011 | 1 | |
| 4JJ1X | 2010 | 1 | |
| 4JJ1X | 2009 | 1 | |
| 4JJ1X | 2008 | 1 | |
| 4JX1T | 1998 | 1 | |
| 4JX1TC | 1998 | 1 | |
| 4JX1T | 1998 | 1 | |
| 4JX1T | 1998 | 1 | |
| 4JJ1E5N | 2013 | 1 |
