Specification
DOWNLOAD SPECS| Length | 10.24 inch / 260.00 mm |
| Gasket OD | 4.02 inch / 102.20 mm |
| Rated Flow | 23.78 gpm / 90.00 L/min |
| Pressure Valve Opening Pressure | 0.10 kPa |
| Pressure Valve | No |
| Media Type | Cellulose |
| Thread Size | M32X1.5-6H |
| Largest OD | 4.33 inch / 110.00 mm |
| Efficiency Test Std | ISO 4548-12 |
| Gasket Inside Diameter | 3.71 inch / 94.20 mm |
| Hydrostatic Burst Minimum | 217.50 psi / 1500.00 kPa |
| Primary Particle Efficiency | 45.00 micron (c) @ 98.7% |
| Test Specification | ISO 4548-12 |
| Applicable Region | North America, Europe, South America, South East Asia |
Product Comments
100.000km Change Interval
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| D13K | 2021 | 1 | |
| D13K | 2021 | 1 | |
| D13K | 2021 | 1 | |
| D13K | 2021 | 1 | |
| D13K | 2021 | 1 | |
| D13K460 | 2016 | 1 | |
| D13K500 | 2016 | 1 | |
| D16K | 2014 | 1 | |
| D16K | 2014 | 1 | |
| D13K EURO 6 | 2013 | 1 | |
| D13K EURO 6 | 2013 | 1 | |
| D13K EURO 6 | 2013 | 1 | |
| D13K EURO 6 | 2013 | 1 | |
| D13K | 2013 | 1 | |
| D13K | 2013 | 1 | |
| D13K EURO 6 | 2013 | 1 | |
| D13C | 2013 | 1 | |
| D13C | 2013 | 1 | |
| D13C | 2013 | 1 | |
| D13K EURO 6 | 2013 | 1 | |
| D13K EURO 6 | 2013 | 1 | |
| D13K EURO 6 | 2013 | 1 | |
| D13K | 2013 | 1 | |
| D16G | 2013 | 1 | |
| DTI13 | 2013 | 1 | |
| DTI13 | 2013 | 2 | |
| DTI13 | 2013 | 2 | |
| DTI13 | 2013 | 1 | |
| DTI13 | 2013 | 2 | |
| DTI13 | 2013 | 2 | |
| DTI13 | 2013 | 1 | |
| DTI13 | 2013 | 1 | |
| DTI13 | 2013 | 2 |
