Specification
DOWNLOAD SPECS| Thread Size | M30X1.5-6H |
| Gasket Inside Diameter | 2.91 inch / 74.04 mm |
| Largest OD | 4.27 inch / 108.53 mm |
| Hydrostatic Burst Minimum | 290.00 psi / 2000.00 kPa |
| Primary Particle Efficiency | 24.60 micron (c) @ 95% |
| Gasket OD | 3.29 inch / 83.60 mm |
| Length | 5.14 inch / 130.56 mm |
| Pressure Valve | Yes |
| Rated Flow | 7.40 gpm / 28.00 L/min |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific, Mexico and Central America |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 6 CYL (4.0L) 2H DIESEL | 1990 | 1 | |
| 6 CYL 12HT TURBO DIESEL | 1990 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1990 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1990 | 1 | |
| 6 CYL 12HT TURBO DIESEL | 1989 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1989 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1989 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1989 | 1 | |
| 6 CYL 12HT TURBO | 1989 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1988 | 1 | |
| 6 CYL 12HT TURBO DIESEL | 1988 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1988 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1988 | 1 | |
| 12HT | 1988 | 1 | |
| 6 CYL 12HT TURBO | 1988 | 1 | |
| 6 CYL 12HT TURBO DIESEL | 1987 | 1 | |
| V6 1HZ | 1987 | 1 | |
| V6 1HZ | 1987 | 1 | |
| 6 CYL 12HT TURBO | 1987 | 1 | |
| V6 2H | 1987 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1987 | 1 | |
| V6 2H | 1987 | 1 | |
| V6 1HZ | 1987 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1987 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1987 | 1 | |
| V6 2H | 1987 | 1 | |
| V6 | 1986 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1986 | 1 | |
| 6 CYL 12HT TURBO DIESEL | 1986 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1986 | 1 | |
| 6 CYL 12HT TURBO | 1986 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1986 | 1 | |
| V6 | 1985 | 1 | |
| 12HT | 1985 | 1 | |
| 12HT | 1985 | 1 | |
| V6 | 1984 | 1 | |
| V6 | 1983 | 1 | |
| 2H | 1983 | 1 | |
| 2H | 1982 | 1 | |
| 2H | 1982 | 1 | |
| 2H | 1982 | 1 | |
| 2H | 1982 | 1 | |
| 2H | 1982 | 1 | |
| (4.0L) 6 CYL. 2H | 1981 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1981 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1981 | 1 | |
| (4.0L) 6 CYL. 2H | 1981 | 1 | |
| 1981 | 1 | ||
| 6 CYL (4.0L) 2H DIESEL | 1981 | 1 | |
| 1980 | 1 | ||
| 6 CYL (4.0L) 2H DIESEL | 1980 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1980 | 1 | |
| 6 CYL (4.0L) 2H DIESEL | 1980 | 1 | |
| 2H | 1 | ||
| 2H | 1 | ||
| 1 | |||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 4.0L DIESEL | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H DIESEL | 1 | ||
| 1 | |||
| 2H | 1 | ||
| 1 | |||
| 2H | 1 | ||
| 2H | 1 | ||
| 1 | |||
| 2H | 1 | ||
| 1 | |||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H DIESEL | 1 | ||
| 2H | 1 | ||
| 2H DIESEL | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 1 | |||
| 2H | 1 | ||
| 2H DIESEL | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 1 | |||
| 2H | 1 | ||
| 2H DIESEL | 1 | ||
| 1 | |||
| 2H | 1 | ||
| 1 | |||
| 1 | |||
| 2H | 1 | ||
| 2H DIESEL | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 1 | |||
| 2H DIESEL | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2H | 1 | ||
| 2J | 1 | ||
| 2F | 1 | ||
| NH | 1 |
