Specification
DOWNLOAD SPECS| Thread Size | 1.00 1/8-16 UN-2B |
| Gasket Outside Diameter | 3.95 inch / 100.23 mm |
| Height | 7.09 inch / 180.09 mm |
| Hydrostatic Burst Minimum | 246.50 psi / 1700.00 kPa |
| Media Type | Cellulose |
| Gasket Inside Diameter | 3.59 inch / 91.31 mm |
| Largest Outside Diameter | 4.24 inch / 107.67 mm |
| Pressure Valve | No |
| Rated Flow | 29.06 gpm / 110.00 L/min |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific, Mexico and Central America |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| NE6T | 1986 | 1 | |
| NE6T | 1986 | 1 | |
| NE6T | 1986 | 1 | |
| FE6A | 1 | ||
| NE6T | 1 | ||
| NE6T | 2 | ||
| NE6 | 1 | ||
| NE6T (210 HP ) DIESEL | 1 | ||
| NE6T | 2 | ||
| NE6T | 1 | ||
| NE6T | 1 | ||
| NE6T | 1 | ||
| NE6 | 1 | ||
| NE-6 (175 HP) DIESEL | 1 | ||
| NE6T | 1 | ||
| 1004-40 | 1 | ||
| 1004-40 | 1 | ||
| 1004-40 | 1 | ||
| 1004-40 | 1 | ||
| PERKINS | 1 | ||
| 1004-40 | 1 | ||
| 1004-40 | 1 | ||
| 3126TA | 1 |
