Specification
DOWNLOAD SPECS| Thread Size | 1-12 UNF 2B |
| Gasket OD | 2.83 inch / 71.98 mm |
| Length | 8.10 inch / 205.62 mm |
| Hydrostatic Burst Minimum | 203.00 psi / 1400.00 kPa |
| Primary Particle Efficiency | 24.60 micron (c) @ 99% |
| Gasket Inside Diameter | 2.46 inch / 62.53 mm |
| Largest OD | 3.69 inch / 93.78 mm |
| Pressure Valve | No |
| Rated Flow | 14.53 gpm / 55.00 L/min |
| Applicable Region | North America, Europe, South East Asia, South Pacific, Mexico and Central America |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| DTA360 | 1 | ||
| DTA360 | 2 | ||
| DT360 | 2 | ||
| DT466 | 1980 | 1 |
