Specification
DOWNLOAD SPECS| Length | 3.90 inch / 99.00 mm |
| Media Type | Cellulose |
| Thread Size | 3/4-1.59 UNF 2B |
| Gasket Inside Diameter | 2.62 inch / 66.50 mm |
| Rated Flow | 3.96 gpm / 15.00 L/min |
| Largest OD | 3.75 inch / 95.20 mm |
| Efficiency Test Std | ISO 4548-12 |
| Primary Particle Efficiency | 50.00 micron (c) @ 98.7% |
| Pressure Valve | No |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 1006-6 | 1 | ||
| LD23EGR | 1999 | 1 | |
| GQ ST & TI 4.2L EFI TB42E | 1997 | 1 | |
| GQ ST & TI 4.2L EFI TB42E | 1996 | 1 | |
| GQ ST & TI 4.2L EFI TB42E | 1995 | 1 | |
| Z20 | 1995 | 1 | |
| GQ 4.2L (TB42S) | 1995 | 1 | |
| Z20 | 1994 | 1 | |
| GQ ST & TI 4.2L EFI TB42E | 1994 | 1 | |
| GQ 4.2L (TB42S) | 1994 | 1 | |
| 1993 | 1 | ||
| GQ ST & TI 4.2L EFI TB42E | 1993 | 1 | |
| GQ 4.2L (TB42S) | 1993 | 1 | |
| Z20 | 1993 | 1 | |
| GQ 4.2L (TB42S) | 1992 | 1 | |
| 2.4 L | 1992 | 1 | |
| 1992 | 1 | ||
| GQ ST & TI 4.2L EFI TB42E | 1992 | 1 | |
| Z20 | 1992 | 1 | |
| Z20 | 1991 | 1 | |
| GQ 4.2L (TB42S) | 1991 | 1 | |
| 2.4 L | 1991 | 1 | |
| 2.4 L | 1990 | 1 | |
| Z20 | 1990 | 1 | |
| GQ 4.2L (TB42S) | 1990 | 1 | |
| GQ 4.2L (TB42S) | 1989 | 1 | |
| Z20 | 1989 | 1 | |
| L4-2.4L-2389 CC-Z24 | 1989 | 1 | |
| 2.4 L | 1989 | 1 | |
| L4-2.4L-2389 CC-Z24 | 1989 | 1 | |
| GQ 4.2L (TB42S) | 1988 | 1 | |
| L4-2.4L-2389 CC-Z24 | 1988 | 1 | |
| 2.4 L | 1988 | 1 | |
| L4-2.4L-2389 CC-Z24 | 1988 | 1 | |
| Z20 | 1988 | 1 | |
| Z20 | 1987 | 1 | |
| LD20 DIESEL | 1987 | 1 | |
| 1987 | 1 | ||
| MQ | 1987 | 1 | |
| 2.4 L | 1987 | 1 | |
| L4-2.4L-2389 CC-Z24 | 1987 | 1 | |
| L28 | 1987 | 1 | |
| GQ 4.2L (TB42S) | 1987 | 1 | |
| MK | 1987 | 1 | |
| L4-2.4L-2389 CC-Z24 | 1987 | 1 | |
| MQ | 1986 | 1 | |
| L4-2.4L-2389 CC-Z24 | 1986 | 1 | |
| MK | 1986 | 1 | |
| 1986 | 1 | ||
| L4-2.4L-2389 CC-Z24 | 1986 | 1 | |
| 4 CYL (2.4 L) | 1986 | 1 | |
| 2.4 L | 1986 | 1 | |
| Z20 | 1986 | 1 | |
| L28 | 1986 | 1 | |
| 1986 | 1 | ||
| Z22 | 1986 | 1 | |
| L4-2.4L-2389 CC-Z24I | 1986 | 1 | |
| L28 | 1985 | 1 | |
| L4-2.0L-1952 CC-Z20 | 1985 | 1 | |
| Z22 | 1985 | 1 | |
| MK | 1985 | 1 | |
| L4-2.4L-2389 CC-Z24 | 1985 | 1 | |
| MQ | 1985 | 1 | |
| L4-2.0L-1952 CC-Z20 | 1984 | 1 | |
| MQ | 1984 | 1 | |
| Z22 | 1984 | 1 | |
| L28 | 1984 | 1 | |
| MK | 1984 | 1 | |
| L4-2.4L-2389 CC-Z24 | 1984 | 1 | |
| L6-2.4L-2393 CC-L24E | 1984 | 1 | |
| L6-2793 CC (2.8L) TURBO | 1983 | 1 | |
| L4-2187 CC (2.2L) EFI | 1983 | 1 | |
| L4-2389 CC (2.4L) CARB | 1983 | 1 | |
| L6-2393 CC (2.4L) EFI | 1983 | 1 | |
| L28 | 1983 | 1 | |
| Z22 | 1983 | 1 | |
| L6-2793 CC (2.8L) EFI | 1983 | 1 | |
| MK | 1983 | 1 | |
| MQ | 1983 | 1 | |
| L4-1952 CC (2.0L) CARB | 1983 | 1 | |
| L4-2187 CC (2.2L) CARB | 1982 | 1 | |
| L6-2793 CC (2.8L) EFI | 1982 | 1 | |
| L4-2187 CC (2.2L) EFI | 1982 | 1 | |
| L6-2393 CC (2.4L) EFI | 1982 | 1 | |
| L6-2793 CC (2.8L) TURBO | 1982 | 1 | |
| LD20 DIESEL | 1981 | 1 | |
| 6 CYL (2.4L) 2393 CC | 1981 | 1 | |
| L6-2.8L-2793 CC-LD28 | 1981 | 1 | |
| FD46TA-U2 | 1 | ||
| TB42 | 1 | ||
| LD40 DIESEL | 1 | ||
| LD 20T | 1 | ||
| TB42 | 1 | ||
| 1982 | 1 | ||
| 4 CYL (2.2L) 2187 CC | 1981 | 1 | |
| 6 CYL (2.8L) 2793 CC | 1981 | 1 | |
| CARB | 1981 | 1 | |
| 4 CYL (2.0L) 1952 CC | 1981 | 1 | |
| 4 CYL (2.0L) 1952 CC | 1981 | 1 | |
| CARB | 1981 | 1 | |
| EFI | 1981 | 1 | |
| CARB | 1980 | 1 | |
| 4 CYL (2.0L) 1952 CC | 1980 | 1 | |
| EFI | 1980 | 1 | |
| 6 CYL (2.8L) 2793 CC | 1980 | 1 | |
| 4 CYL (2.0L) 1952 CC | 1980 | 1 | |
| CARB | 1980 | 1 | |
| 4 CYL (2.0L) 1952 CC | 1980 | 1 | |
| 6 CYL (2.8L) 2793 CC | 1979 | 1 | |
| CARB | 1979 | 1 | |
| 4 CYL (2.0L) 1952 CC | 1979 | 1 | |
| 4 CYL (2.0L) 1952 CC | 1979 | 1 | |
| CARB | 1979 | 1 | |
| CARB | 1978 | 1 | |
| 4 CYL (2.0L) 1952 CC | 1978 | 1 | |
| 4 CYL (2.0L) 1952 CC | 1978 | 1 | |
| CARB | 1978 | 1 | |
| CARB | 1977 | 1 | |
| 4 CYL (2.0L) 1952 CC | 1977 | 1 | |
| 4 CYL (2.0L) 1952 CC | 1975 | 1 | |
| CARB | 1975 | 1 | |
| 1 |
