Specification
DOWNLOAD SPECS| Thread Size | M22X1.5-6H |
| Gasket Inside Diameter | 2.46 inch / 62.53 mm |
| Largest OD | 3.06 inch / 77.82 mm |
| Hydrostatic Burst Minimum | 203.00 psi / 1400.00 kPa |
| Primary Particle Efficiency | 24.60 micron (c) @ 95% |
| Gasket OD | 2.83 inch / 71.98 mm |
| Length | 4.58 inch / 116.33 mm |
| Pressure Valve | Yes |
| Rated Flow | 2.91 gpm / 11.00 L/min |
| Applicable Region | North America, China, Europe, South America, South East Asia, South Pacific, Mexico and Central America |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| L317D-I 3 CYL DIESEL | 1 | ||
| L317D-M 3 CYL DIESEL | 1 | ||
| L-317 DIESEL | 1 | ||
| L-317 MARINE DIESEL | 1 |
