Specification
DOWNLOAD SPECS| Thread Size | 2.25-12 UNF 2B |
| Gasket Inside Diameter | 4.01 inch / 101.85 mm |
| Length | 9.36 inch / 237.62 mm |
| Rated Flow | 19.87 gpm / 75.20 L/min |
| Primary Particle Efficiency | 30.00 micron (c) @ 98% |
| Gasket OD | 4.68 inch / 118.87 mm |
| Largest OD | 4.68 inch / 118.87 mm |
| Efficiency Test Std | SAE J1858 |
| Hydrostatic Burst Minimum | 275.94 psi / 1903.00 kPa |
| Applicable Region | North America, China, Europe, South America, South East Asia, South Pacific, Mexico and Central America |
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| ISL9 | 2009 | 1 | |
| ISL9 | 2008 | 1 | |
| ISC8.3 | 1998 | 1 | |
| ISC8.3 | 1 | ||
| ISC8.3 | 1 | ||
| ISC8.3 | 1 | ||
| ISL9 | 1 | ||
| ISC8.3 | 1 | ||
| C8.3 | 1 | ||
| ISL9 | 1 | ||
| ISL9 | 1 | ||
| ISC8.3 | 1 | ||
| ISC8.3 | 1 | ||
| SA6D114-1 | 2004 | 1 | |
| SA6D114-1 | 2004 | 1 | |
| SA6D114 | 2004 | 1 | |
| SA6D114-1 | 2004 | 1 | |
| SA6D114-1 | 2004 | 1 | |
| SA6D114-1 | 2004 | 1 | |
| SA6D114 | 2004 | 1 | |
| 1 | |||
| 1 | |||
| 614T | 1 | ||
| 1 | |||
| D505T | 1 | ||
| 1 | |||
| 1 | |||
| D505T | 1 | ||
| S6D114E-1 | 1 | ||
| 1 | |||
| 614T | 1 | ||
| D505T | 1 | ||
| 1 | |||
| SA6D114-1 | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| S6D114E | 1 | ||
| SAA6D114E-1 | 1 | ||
| D505T | 1 | ||
| 1 | |||
| S6D114E-1 | 1 | ||
| ISC8.3 | 1 | ||
| ISC8.3 | 2010 | 1 | |
| 8.3L | 2007 | 1 | |
| ISL9 | 1 | ||
| ISL9 | 1 | ||
| ISC8.3 | 1 | ||
| ISL9 | 1 | ||
| 6TAA-8304 | 2009 | 1 | |
| 6TAA-8304 | 2009 | 1 | |
| 6TAA-8304 | 2009 | 1 | |
| CUMMINS | 2006 | 1 | |
| 1998 | 1 | ||
| 1998 | 1 | ||
| 1998 | 1 | ||
| 1998 | 1 | ||
| 1998 | 1 | ||
| 6T830 | 1991 | 1 | |
| 6T8.3 | 1991 | 1 | |
| 6T8.3 | 1991 | 1 | |
| 6T830 | 1991 | 1 | |
| 6CTA8.3 | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| 1 | |||
| 6C8.3 | 1 | ||
| 6TA-830 | 1 | ||
| 1 | |||
| 6-830 | 1 | ||
| 1 | |||
| 1 | |||
| 8.3L | 1 | ||
| 6T830 | 1 | ||
| 1 | |||
| 6C8.3 | 1 | ||
| 1 | |||
| 6T830 | 1 | ||
| 6CT8.3 | 1 | ||
| 1 | |||
| 8.3L | 1 | ||
| 1 | |||
| 1 | |||
| 8.3L | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| 1 | |||
| 8.3L | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| 1 | |||
| 1 | |||
| 1 | |||
| 6CT8.3 | 1 | ||
| 6TA-830 | 1 | ||
| 6T830 | 1 | ||
| 1 | |||
| 8.3L | 1 | ||
| 6T830 | 1 | ||
| 1 | |||
| 6CTA8.3 | 1 | ||
| 6-830 | 1 | ||
| 1 | |||
| 6TA-830 | 1 | ||
| 6C8.3 | 1 | ||
| 6CT8.3 | 1 | ||
| 8.3L | 1 | ||
| 6CTA8.3 | 1 | ||
| 1 | |||
| 6TA-830 | 1 | ||
| 6CTA8.3 | 1 | ||
| 6CT8.3 | 1 | ||
| 1 | |||
| 1 | |||
| 6CT8.3 | 1 | ||
| 1 | |||
| 6T830 | 1 | ||
| 1 | |||
| 1 | |||
| 8.3L | 1 | ||
| 6T830 | 1 | ||
| 6CTA8.3 | 1 | ||
| 6TA-830 | 1 | ||
| 1 | |||
| 6C8.3 | 1 | ||
| 6TA (8.3L) | 1 | ||
| 1 | |||
| 6831TA | 1 | ||
| 6T-830 | 1 | ||
| 6CT8.3 | 1 | ||
| 1 | |||
| 1 | |||
| 6CT8.3 | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| 6TA (8.3L) | 1 | ||
| 1 | |||
| 8.3L | 1 | ||
| 1 | |||
| 1 | |||
| 6T830 | 1 | ||
| 6CTA8.3 | 1 | ||
| 6CT8.3 | 1 | ||
| 6-830 | 1 | ||
| 6TA-830 | 1 | ||
| 1 | |||
| 6C8.3 | 1 | ||
| 1 | |||
| C8.3-C | 2005 | 1 | |
| C8.3-C | 2005 | 1 | |
| 6CTA8.3 | 1 | ||
| 6CT8.3 | 1 | ||
| 6CTA8.3 | 1 | ||
| 6CTA8.3 | 1 | ||
| 6CTA8.3 | 1 | ||
| N14 PLUS | 1 | ||
| ISC | 2022 | 1 | |
| TIER III | 2008 | 1 | |
| 8.3L TURBO | 2006 | 1 | |
| 8.3L TURBO | 2006 | 1 | |
| 2002 | 1 | ||
| 2002 | 1 | ||
| 2002 | 1 | ||
| 2002 | 1 | ||
| ISC8.3 | 1 | ||
| 6CTA8.3 | 1 | ||
| 8.3L | 1 | ||
| 6CT8.3 | 1 | ||
| CDC 6T-830 | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| CUMMINS | 1 | ||
| 6CTA8.3 | 1 | ||
| 1 | |||
| 1 | |||
| 6CT8.3 | 1 | ||
| 8.3L | 1 | ||
| 1 | |||
| D505T | 1 | ||
| CUMMINS | 1 | ||
| C8.3-C | 1 | ||
| CUMMINS | 1 | ||
| CUMMINS | 1 | ||
| 1 | |||
| 6CT8.3 | 1 | ||
| CUMMINS | 1 | ||
| D505T | 1 | ||
| C8.3-C | 1 | ||
| CUMMINS | 1 | ||
| D505T | 1 | ||
| VALMET | 1 | ||
| CUMMINS | 1 | ||
| 1 | |||
| D505T | 1 | ||
| 6CTA-830 | 1 | ||
| 1 | |||
| 1 |
