Specification
DOWNLOAD SPECS| Thread Size | 1-16 UNF 2B |
| Gasket Inside Diameter | 2.46 inch / 62.53 mm |
| Largest OD | 3.69 inch / 93.78 mm |
| Rated Flow | 8.72 gpm / 33.00 L/min |
| Pressure Valve | No |
| Test Specification | SAE J1858 |
| Gasket OD | 2.83 inch / 71.98 mm |
| Length | 6.94 inch / 176.20 mm |
| Efficiency Test Std | SAE J1858 |
| Hydrostatic Burst Minimum | 203.00 psi / 1400.00 kPa |
| Primary Particle Efficiency | 24.60 micron (c) @ 95% |
| Length / Overall Height | 6.94 inch / 176.20 mm |
| Applicable Region | North America, Europe, South East Asia, South Pacific, Mexico and Central America |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| DB58T | 2004 | 1 | |
| 1 | |||
| 1 | |||
| DB58T | 1 | ||
| DB58T | 1 | ||
| DB33 | 1 | ||
| DB58 | 1 | ||
| 1 | |||
| DB58 | 1 |
