Specification
DOWNLOAD SPECS| Thread Size | 3/4-16 UNF 2B |
| Gasket OD | 2.83 inch / 71.98 mm |
| Length | 3.39 inch / 86.23 mm |
| Hydrostatic Burst Minimum | 203.00 psi / 1400.00 kPa |
| Primary Particle Efficiency | 24.60 micron (c) @ 95% |
| Gasket Inside Diameter | 2.46 inch / 62.54 mm |
| Largest OD | 3.69 inch / 93.61 mm |
| Pressure Valve | Yes |
| Rated Flow | 3.43 gpm / 13.00 L/min |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific, Mexico and Central America |
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 2013 | 1 | ||
| V2203M | 1 | ||
| V 1703 | 2012 | 1 | |
| V2203 | 2014 | 1 | |
| V3600 | 2013 | 1 | |
| D1803T | 2021 | 1 | |
| V 2403 CR-T | 2020 | 1 | |
| D1803CRT | 2020 | 1 | |
| V3307-CR-TEW 05 | 2020 | 1 | |
| D1803M-E2 | 2019 | 1 | |
| D1703-M-DI-E4 | 2019 | 1 | |
| D1703 | 2019 | 1 | |
| V2403MEU32 | 2019 | 1 | |
| V3307-CR5-TE4 | 2018 | 1 | |
| V3307-CR5-TE4 | 2018 | 1 | |
| V3307-CR5-TE4 | 2018 | 1 | |
| V3307-CR5-TE4 | 2018 | 1 | |
| D1703 | 2018 | 1 | |
| V2403 | 2016 | 1 | |
| D 1803 M-E3-BH | 2016 | 1 | |
| V 2203-EU1 | 2015 | 1 | |
| D 1803 M-E3-BH | 2015 | 1 | |
| D1503 | 2015 | 1 | |
| D 1803 M-E3-BH | 2014 | 1 | |
| V 2403-T | 2013 | 1 | |
| D 1803 M-E3-BH | 2013 | 1 | |
| D1703M | 2012 | 1 | |
| V2403 M-T | 2012 | 1 | |
| V2403-M | 2012 | 1 | |
| V2403MEU35 | 2012 | 1 | |
| D1503 | 2012 | 1 | |
| V2403-M | 2012 | 1 | |
| V 2203 EU17 | 2012 | 1 | |
| D 1803 M-E3-BH | 2012 | 1 | |
| V3300DI | 2012 | 1 | |
| V2403-M-DI | 2012 | 1 | |
| V 3600 T-EU2 | 2012 | 1 | |
| V 3600 T-EU2 | 2012 | 1 | |
| D 1503-M-EBH-3 | 2011 | 1 | |
| D 1503-M-EBH-3 | 2011 | 1 | |
| V2403MEU35 | 2011 | 1 | |
| V3307-DI-T | 2011 | 1 | |
| V3600 | 2011 | 1 | |
Hunan Sunward Machinery (HUNAN SUNWARD MACHINERY) - SWE 90 N9 | V3800-DITE2B | 2011 | 1 |
| D1703 | 2011 | 1 | |
| D 1703-EU32 | 2011 | 1 | |
| V 3600 TET02 | 2011 | 1 | |
| D1703 | 2011 | 1 | |
| V 2205 | 2011 | 1 | |
| D 1503 M-EBH 2 | 2011 | 1 | |
| D 1803 M-E3-BH | 2011 | 1 | |
| V 3307-DIT-ET02 | 2011 | 1 | |
| D 1503-M-EBH-3 | 2011 | 1 | |
| D 1503-M-EBH-3 | 2010 | 1 | |
| V 2403-T | 2010 | 1 | |
| V2203-M | 2010 | 1 | |
| V2203-M | 2010 | 1 | |
| V 2003 MT | 2010 | 1 | |
| V 3800 TDI | 2010 | 1 | |
| V3307-DI-T | 2010 | 1 | |
| V3307-DI-T | 2010 | 1 | |
| V3600 | 2010 | 1 | |
| D 1503-M-ET03 | 2010 | 1 | |
| D 1503-M-ET03 | 2010 | 1 | |
| V2607DI | 2010 | 1 | |
| V 2203 M-EU33 | 2010 | 1 | |
| V 2203 M-EU33 | 2010 | 1 | |
| V 2203 M-EU33 | 2010 | 1 | |
| D 1803 M-E3-BH | 2010 | 1 | |
| V 2403-T | 2010 | 1 | |
| V 2403-T | 2010 | 1 | |
| D 1503 M-EBH 2 | 2010 | 1 | |
| V2403-M | 2010 | 1 | |
| V 3307-DIT-ET02 | 2010 | 1 | |
| D 1503-M-EBH-3 | 2010 | 1 | |
| V 2403-T | 2010 | 1 | |
| V 2403-T | 2010 | 1 | |
| V 2403-T | 2010 | 1 | |
| V 2403-T | 2010 | 1 | |
| V 2403-T | 2010 | 1 | |
| D 1503-M-EBH-3 | 2010 | 1 | |
| V2403MEU32 | 2010 | 1 | |
| V 3307 D1TE3B | 2010 | 1 | |
| D 1503-M-EBH-3 | 2009 | 1 | |
| D 1503-M-EBH-3 | 2009 | 1 | |
| V 3800 DIT-E3B | 2009 | 1 | |
| V 3800-DI | 2009 | 1 | |
| V 3800 DITET02 | 2009 | 1 | |
| V2403 M-T | 2009 | 1 | |
| D 1503-M-EBH-3 | 2009 | 1 | |
| D 1503 M-EBH 2 | 2009 | 1 | |
| D 1503 M-EBH 2 | 2008 | 1 | |
| V 2403-M-E2B | 2008 | 1 | |
| D 1503-M-EBH-3 | 2008 | 1 | |
| V 2203-EUA | 2008 | 1 | |
| V2403 | 2008 | 1 | |
| D 1703 EU1 | 2008 | 1 | |
| V3800DIT | 2008 | 1 | |
| V2403 | 2008 | 1 | |
| V2403 | 2008 | 1 | |
| D 1503-M-EBH-3 | 2008 | 1 | |
| D 1503-M-EBH-3 | 2008 | 1 | |
| D1402-BH4 | 1991 | 1 | |
| V1902-BH2 | 1990 | 1 | |
| 1 | |||
| D1402 | 1 | ||
| D1703 | 1 | ||
| V2203 | 1 | ||
| V2203-KA | 1 | ||
| V2203-B | 1 | ||
| S2800-A | 1 | ||
| D1703-M-E3 | 1 | ||
| 1 | |||
| 1 | |||
| KUBOTA | 1 | ||
| 6 CYL 2598 CC | 1 | ||
| 1 | |||
| V2203-M-E3 | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| S2800-A | 1 | ||
| 1 | |||
| V2003-T | 1 | ||
| D1503E | 1 | ||
| 1 | |||
| V2203-B | 1 | ||
| 1 | |||
| V2203 | 2 | ||
| V2203A | 1 | ||
| 1 | |||
| V2203-M-E3 | 1 | ||
| 4 CYL | 1 | ||
| 1 | |||
| Z482 | 1 | ||
| 1 | |||
| 1 | |||
| V2203-M-E3 | 1 | ||
| 1 | |||
| V2203 | 1 | ||
| COMPACT LINE | 1 | ||
| D1703-M-E3 | 1 | ||
| F2302-DI-L | 1 | ||
| 1 | |||
| F2302-DI-L | 1 | ||
| 6-158.5 | 1 | ||
| COMPACT LINE | 1 | ||
| V2203 | 1 |
