Specification
DOWNLOAD SPECS| Thread Size | 3/4-16 UNF 2B |
| Gasket Inside Diameter | 2.44 inch / 62.00 mm |
| Length | 4.51 inch / 114.60 mm |
| Rated Flow | 10.57 gpm / 40.00 L/min |
| Hydrostatic Burst Minimum | 217.50 psi / 1500.00 kPa |
| Primary Particle Efficiency | 50.00 micron (c) @ 95% |
| Gasket OD | 2.76 inch / 70.00 mm |
| Largest OD | 4.25 inch / 108.00 mm |
| Efficiency Test Std | ISO 4548-12 |
| Pressure Valve Opening Pressure | 250.00 kPa |
| Pressure Valve | Yes |
| Test Specification | ISO 4548-12 |
| Applicable Region | North America, Europe, South East Asia, South Pacific |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 1.9 L TURBO DIESEL | 1992 | 1 | |
| 1.9 L DIESEL | 1990 | 1 | |
| L5-1986 CC (2.0L) | 1983 | 1 | |
| L5-1986 CC (2.0L) | 1982 | 1 | |
| Z8701.12 | 2009 | 1 | |
| Z8701.12 | 2009 | 1 | |
| Z8604.000 | 2009 | 1 | |
| Z8604.000 | 2008 | 1 | |
| Z8701.12 | 2008 | 1 | |
| Z8701.12 | 2008 | 1 | |
| 1 | |||
| 1 | |||
| 1 | |||
| 1 |
