Specification
DOWNLOAD SPECS| Largest OD | 1.65 inch / 42.00 mm |
| Efficiency Test Std | ISO 4548-12 |
| Element Collapse/Burst, Min | 400.00 kPa |
| Gasket Inside Diameter | 0.55 inch / 14.00 mm |
| Primary Particle Efficiency | 57.00 micron (c) @ 98.7% |
| Length | 2.52 inch / 64.00 mm |
| Largest End ID | 0.51 inch / 13.00 mm |
| Rated Flow | 1.35 gpm / 5.10 L/min |
| Pressure Valve | Yes |
| Test Specification | ISO 4548-12 |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 1D42S | 2021 | 1 | |
| 1D42S | 2020 | 1 | |
| 1D50 S | 2020 | 1 | |
| 1D42S | 2019 | 1 | |
| 1 D 90 Z | 2018 | 1 | |
| 1D42S | 2018 | 1 | |
| 1D90V | 2018 | 1 | |
| 1D90V | 2018 | 1 | |
| 1D42S | 2018 | 1 | |
| 1D81 S | 2017 | 1 | |
| 1D42S | 2017 | 1 | |
| 1D42S | 2016 | 1 | |
| 1D42S | 2016 | 1 | |
| 1D42S | 2016 | 1 | |
| 1D50 S | 2015 | 1 | |
| 1B50 | 2015 | 1 | |
| 1D42S | 2015 | 1 | |
| 1D81 S | 2014 | 1 | |
| 1D42S | 2014 | 1 | |
| 1D81 S | 2014 | 1 | |
| 1D50Z | 2014 | 1 | |
| 1D50Z | 2013 | 1 | |
| 1D42S | 2013 | 1 | |
| 1D42S | 2013 | 1 | |
| 1B30-6 | 2012 | 1 | |
| 1D81 S | 2012 | 1 | |
| 1D42S | 2012 | 1 | |
| 1D42S | 2011 | 1 | |
| 1 D 90 Z | 2011 | 1 | |
| 1D42S | 2011 | 1 | |
| 1D81 S | 2011 | 1 | |
| 1D81 S | 2010 | 1 | |
| 1D42S | 2010 | 1 | |
| 1 D 81 Z | 2008 | 1 | |
| HATZ | 2006 | 1 | |
| HATZ | 2006 | 1 | |
| HATZ | 2006 | 1 | |
| HATZ | 2006 | 1 | |
| HATZ | 2006 | 1 | |
| 1D80 | 1991 | 1 | |
| 1D80 | 1991 | 1 | |
| 1D80 | 1991 | 1 | |
| 1D90V | 1 | ||
| 1D41S | 1 | ||
| 1D90V | 1 | ||
| OSW1D10 | 1 | ||
| SUPRA 1D81Z | 1 | ||
| HATZ | 1 | ||
| 1D85Z | 1 | ||
| 1D41S | 1 | ||
| 1 | |||
| 1D80 | 1 | ||
| SUPRA 1D41S | 1 | ||
| 1D41S | 1 | ||
| 1D812 | 1 | ||
| 1D80C | 1 | ||
| 1D60Z | 1 | ||
| 1D60 | 1 | ||
| 1D41S | 1 | ||
| 1 | |||
| 1D40S | 1 |
