Specification
DOWNLOAD SPECS| Thread Size | 3/4-16 UNF 2B |
| Gasket OD | 2.83 inch / 71.98 mm |
| Largest OD | 3.78 inch / 96.06 mm |
| Pressure Valve | Yes |
| Primary Particle Efficiency | 24.60 micron (c) @ 68% |
| Gasket Inside Diameter | 2.46 inch / 62.53 mm |
| Length | 5.40 inch / 137.08 mm |
| Hydrostatic Burst Minimum | 217.50 psi / 1500.00 kPa |
| Rated Flow | 15.85 gpm / 60.00 L/min |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific, Mexico and Central America |
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| PHASER 210TI | 1986 | 1 | |
| V8 | 2012 | 1 | |
| V8 | 2012 | 1 | |
| V8 7.0L | 2012 | 1 | |
| V8 | 2012 | 1 | |
| V8 6.4L | 2012 | 1 | |
| V8 (5.9L) | 2012 | 1 | |
| L4-2.0L-1989 CC-3 | 1997 | 1 | |
| L4-2.0L-1989 CC-3 | 1996 | 1 | |
| L4-2.0L-1989 CC-3 | 1995 | 1 | |
| V8-370 (6.1 L) | 1982 | 1 | |
| V8-370 (6.1 L) | 1979 | 1 | |
| V8-475 | 1977 | 1 | |
| V8-359 | 1974 | 1 | |
| V8-389 | 1973 | 1 | |
| V8-429 (7.0 L) | 1971 | 1 | |
| V8-391 | 1970 | 1 | |
| 1968 | 1 | ||
| V8-361 | 1964 | 1 | |
| V8-534 | 1958 | 1 | |
| V8-477 (7.8 L) | 1958 | 1 | |
| V8 | 1 | ||
| 1 | |||
| V8 370 GAS | 1 | ||
| 7.0L | 1 | ||
| 7.0L | 1 | ||
| 256 DIESEL | 1 | ||
| 7.0L | 1 | ||
| 1 | |||
| V8 | 1 | ||
| V8 361 5.9L | 1 | ||
| V8 | 1 | ||
| V8 | 1 | ||
| 6.4L | 1 | ||
| 7.0L | 1 | ||
| 6.1L | 1 | ||
| V8 7.0L | 1 | ||
| V8 | 1 | ||
| 1992 | 1 | ||
| L4-2.0L-1989 CC-3 | 1997 | 1 | |
| L4-2.0L-1989 CC-3 | 1996 | 1 | |
| L4-2.0L-1989 CC-3 | 1995 | 1 | |
| 1004.4T | 1 | ||
| 4.108 | 1 | ||
| 4.108 | 1 | ||
| 4-114 | 1 | ||
| 4.108 | 1 | ||
| PERKINS | 1 | ||
| 4.108 | 1 | ||
| 4.108 | 1 | ||
| 4.154 | 1 | ||
| 4-114 | 1 | ||
| 4.248 | 1 | ||
| PERKINS | 1 | ||
| 1004.4T | 1 | ||
| 4.248 | 1 | ||
| PHASER 210TI | 1 | ||
| 4.108 | 1 | ||
| 4.108 | 1 | ||
| 4.108 | 1 | ||
| 4.248 | 1 | ||
| 1004.4T | 1 | ||
| 4.108 | 1 | ||
| 4.108 | 1 | ||
| PERKINS | 1 | ||
| 4.248 | 1 | ||
| 4.108 | 1 | ||
| 4-114 | 1 | ||
| 4.108 | 1 |
