Specification
DOWNLOAD SPECS| Thread Size | 1-12 UNF 2B |
| Gasket Inside Diameter | 2.46 inch / 62.54 mm |
| Largest OD | 3.78 inch / 96.09 mm |
| Hydrostatic Burst Minimum | 203.00 psi / 1400.00 kPa |
| Primary Particle Efficiency | 24.60 micron (c) @ 95% |
| Gasket OD | 2.83 inch / 71.98 mm |
| Length | 6.88 inch / 174.75 mm |
| Pressure Valve | Yes |
| Rated Flow | 7.66 gpm / 29.00 L/min |
| Applicable Region | North America, Europe, South America, South East Asia, South Pacific, Mexico and Central America |
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| 4D120 | 1 | ||
| 4D92 | 1 | ||
| 466B | 1 | ||
| 4D92 | 1 |
