Specification
DOWNLOAD SPECS| Thread Size | 7/8-16 UNF 2B |
| Gasket Inside Diameter | 2.46 inch / 62.59 mm |
| Length | 7.14 inch / 181.23 mm |
| Hydrostatic Burst Minimum | 246.50 psi / 1700.00 kPa |
| Length / Overall Height | 7.14 inch / 181.23 mm |
| Gasket OD | 2.82 inch / 71.63 mm |
| Largest OD | 4.26 inch / 108.20 mm |
| Pressure Valve | No |
| Rated Flow | 11.62 gpm / 44.00 L/min |
| Primary Particle Efficiency | 24.60 micron (c) @ 95% |
| Applicable Region | North America, Europe, South East Asia, South Pacific, Mexico and Central America |
Related Parts
SEE ALL EQUIPMENT SEARCH RESULTS
| Equipment | Engine | Year | Qty. Req. |
|---|---|---|---|
| BM D45B | 1999 | 1 | |
| TD45D | 1986 | 1 | |
| 4.236 | 1978 | 1 | |
| 4.236 | 1978 | 1 | |
| TD45 | 1977 | 1 | |
| TD45 | 1977 | 1 | |
| D45 | 1 | ||
| BM TD4JB | 1 | ||
| TD45B | 1 | ||
| TD45 | 1 | ||
| D45 | 1 | ||
| D45B | 1 | ||
| D45B | 1 | ||
| D45 | 1 | ||
| D45 | 1 | ||
| TD45B | 1 | ||
| TD45 | 1 | ||
| 1 | |||
| 504 | 1 | ||
| 504 | 1 | ||
| 1 | |||
| 1 | |||
| CASEI | 1 | ||
| 504 | 1 | ||
| CASEI | 1 | ||
| 1 | |||
| CASEI | 1 | ||
| 1 | |||
| A504BDT | 1 | ||
| A504D | 1 | ||
| 504BD | 1 | ||
| BM D45B | 1 | ||
| BM TD45B | 1 | ||
| 504BD | 1 | ||
| 1 | |||
| D45B | 1 | ||
| 504BDT | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| 1 | |||
| 504BT | 1 |
